FA and Machine Vision Lenses
-
M118FM16
-
-
2022.12
2050.01
Imager Size Focal Length Aperture Range Iris -
Focus angle : 180deg
IRIS angle : 93.5deg
| Model No. | M118FM16 | |||
|---|---|---|---|---|
| Imager Size | 1/1.8" | |||
| Mount Type | C | |||
| Focal Length | 16mm | |||
| Aperture Range | F/1.4 - F/16 | |||
| Field of View Angle (Horizontal x Vertical) |
1/1.8" | 25.9° x 19.5° | ||
| 1/2" | 22.8° x 17.1° | |||
| 1/3" | 17.1° x 12.9° | |||
| Focus Range | 0.1m - ∞ | |||
| Operation | Focus | Manual w/lock | ||
| Iris | Manual w/lock | |||
| Filter Size | M25.5 P=0.5mm | |||
| Wave Length | Visible Light | |||
| TV Distortion | -0.7％ or less | |||
| Weight | 39g 士 3g | |||
| Operating Temperature | -10°C - +60°C | |||
* Specificotions subjected to change without ony notice.
