Network Surveillance Camera Lenses
-
M117VG3817IR
-
-
2022.09
2050.01
Imager Size Focal Length Aperture Range Iris -
| Model No. | M117VG3817IR | ||
|---|---|---|---|
| Imager Size | 1/1.7" | ||
| Mount Type | CS | ||
| Focal Length | 3.8 - 17mm | ||
| Aperture Range | F/1.4 - close | ||
| Angle of View (Horizontal x Vertical) |
1/1.7" | Wide | 121.2° x 67.2° |
| Tele | 28.1° x 16.1° | ||
| 1/1.8" | Wide | 114.2° x 63.5° | |
| Tele | 26.6° x 15.2° | ||
| Focusing Range | 0.3m - ∞ | ||
| Operation | Focus | Manual w/lock | |
| Zoom | Manual w/lock | ||
| Iris | DC Auto Iris | ||
| Back Focal Distance | 8.66mm( in air ) | ||
| Wave Length | Visible Light - Near Infrared | ||
| Operating Voltage | OPEN : 4V CLOSE : 0.5V |
||
| Weight | 180g ± 5g | ||
| Operating Temperature | -20°C - +60°C | ||
* Specificotions subjected to change without ony notice.
