Network Surveillance Camera Lenses
-
M118VG1250IR
-
-
2022.09
2050.01
Imager Size Focal Length Aperture Range Iris -
| Model No. | M118VG1250IR | ||
|---|---|---|---|
| Imager Size | 1/1.8" | ||
| Mount Type | CS | ||
| Focal Length | 12 - 50mm | ||
| Aperture Range | F/1.4 - 360 | ||
| Field of View Angle (Horizontal x Vertical) |
1/1.8" | Wide | 34.0° x 25.5° |
| Tele | 8.5° x 6.4° | ||
| 1/2" | Wide | 29.9° x 22.4° | |
| Tele | 7.5° x 5.6° | ||
| 1/3" | Wide | 22.4° x 16.8° | |
| Tele | 5.6° x 4.2° | ||
| Focusing Range | 1.0m - ∞ | ||
| Operation | Focus | Manual w/lock | |
| Zoom | Manual w/lock | ||
| Iris | DC Auto Iris | ||
| Back Focal Distance | 9.62mm( in air ) | ||
| Wave Length | Visible Light - Near Infrared | ||
| Operating Voltage | OPEN : 4V CLOSE : 0.5V |
||
| Weight | 130g 土 5g | ||
| Operating Temperature | -20°C - +60°C | ||
* Specificotions subjected to change without ony notice.
