Network Surveillance Camera Lenses
-
M118VP413IR
-
-
2022.09
2050.01
Imager Size Focal Length Aperture Range Iris -
| Model No. | M118VP413IR | ||
|---|---|---|---|
| Imager Size | 1/1.8" | ||
| Mount Type | C | ||
| Focal Length | 4.0 - 13mm | ||
| Aperture Range | F/1.5 - Close | ||
| Field of View Angle (Horizontal x Vertical) |
1/1.8" | Wide | 105.4° x 77.6° |
| Tele | 33.0° x 24.8° | ||
| 1/2" | Wide | 91.7° x 67.9° | |
| Tele | 29.0° x 21.8° | ||
| 1/3" | Wide | 67.9° x 50.6° | |
| Tele | 21.8° x 16.3° | ||
| Focusing Range | 0.3m - ∞ | ||
| Operation | Focus | Manual w/lock | |
| Zoom | Manual w/lock | ||
| Iris | P-Iris(Stepping motor switching control) | ||
| Excitation | Bi-Polar Type | ||
| Back Focal Distance | 15.235mm( in air ) | ||
| Wave Length | Visible Light - Near Infrared | ||
| Operating Voltage | 3V- 5V | ||
| Weight | 167g 土 5g | ||
| Operating Temperature | -20°C - +60°C | ||
* Specificotions subjected to change without ony notice.
