Network Surveillance Camera Lenses
-
M13VP288IR
-
-
2022.09
2050.01
Imager Size Focal Length Aperture Range Iris -
| Model No. | M13VP288IR | ||
|---|---|---|---|
| Imager Size | 1/2.7" | ||
| Mount Type | CS | ||
| Focal Length | 2.8 - 8mm | ||
| Aperture Range | F/1.2 - Close | ||
| Field of View Angle (Horizontal x Vertical) |
1/2.7" | Wide | 124.3° x 65.2° |
| Tele | 43° x 24.2° | ||
| 1/3" | Wide | 100.1° x 72.9° | |
| Tele | 35.8° x 26.8° | ||
| 1/4" | Wide | 72.9° x 53.9° | |
| Tele | 26.8° x 20.1° | ||
| Focusing Range | 0.3m - ∞ | ||
| Operation | Focus | Manual w/lock | |
| Zoom | Manual w/lock | ||
| Iris | P-Iris ( Stepping motor switching control ) | ||
| Excitation | Bi-polar Type | ||
| Back Focal Distance | Wide : 8.339mm( in air ) Tele : 14.944mm( in air ) |
||
| Wave Length | Visible Light - Near Infrared | ||
| Operating Voltage Range | 3.0V - 5.0V | ||
| Weight | 68g ± 4g | ||
| Operating Temperature | -20°C - +60°C | ||
* Specificotions subjected to change without ony notice.
