Network Surveillance Camera Lenses
-
M13VP850IR
-
-
2022.09
2050.01
Imager Size Focal Length Aperture Range Iris -
| Model No. | M13VP850IR | ||
|---|---|---|---|
| Imager Size | 1/2.7" | ||
| Mount Type | CS | ||
| Focal Length | 8 - 50mm | ||
| Aperture Length | F/1.6 - Close | ||
| Field of View Angle (Horizontal x Vertical) |
1/2.7" | Wide | 40.2° x 22.6° |
| Tele | 6.6° x 3.8° | ||
| 1/3" | Wide | 33.5° x 25.1° | |
| Tele | 5.6° x 4.2° | ||
| 1/4" | Wide | 25.1° x 18.8° | |
| Tele | 4.2° x 3.2° | ||
| Focus Range | 2m - ∞ | ||
| Operation | Focus | Manual w/lock | |
| Zoom | Manual w/lock | ||
| Iris | P-IRIS( Stepping motor switching control ) | ||
| Excitation | Bi-Polar Type | ||
| Back Focal Distance | 8.08mm( in air ) | ||
| Wave Length | Visible Light - Near Infrared | ||
| Operating Voltage | 3 - 5V | ||
| Weight | 106g 士 10g | ||
| Operation Temperature | -20℃ - 60℃ | ||
* Specificotions subjected to change without ony notice.
