Network Surveillance Camera Lenses
-
13FM04IR
-
-
2022.09
2050.01
Imager Size Focal Length Aperture Range Iris -
| Model No. | 13FM04IR | ||
|---|---|---|---|
| Imager Size | 1/3" | ||
| Mount Type | CS | ||
| Focal Length | 4mm | ||
| Aperture Range | 1.2 - Close | ||
| Field of View Angle (Horizontal x Vertical) |
1/3" | 65.6° x 49.7° | |
| 1/4" | 49.7° x 37.4° | ||
| Focusing Range | 0.2m - ∞ | ||
| Operation | Focus | Manual w/lock | |
| Iris | Manual w/lock | ||
| Filter Size | - | ||
| Bock Focal Distance | 8.57mm( in air ) | ||
| Wave Length | Visible Light - Near Infrared | ||
| Operating Voltage | - | ||
| Weight | 33g 士 3g | ||
| Operating Temperature | -20°C - +60°C | ||
* Specificotions subjected to change without ony notice.
