Model B016

16-300mm F/3.5-6.3 Di II VC PZD MACRO

CANON EF NIKON F SONY A

Expand your options with high‑power zooming from 16mm wide‑angle.

Angle of View (diagonal)	82゜12' - 5゜20'
Optical Construction	16 elements in 12 groups
Minimum Object Distance	0.39m (15.3 in)
Maximum Magnification Ratio	1:2.9 (at f=300mm: MFD 0.39m)
Filter Size	Φ67mm
Maximum Diameter	Φ75mm
Length*1	99.5mm (3.9 in)*
Weight	540g (19 oz)*
Aperture Blades	7 (circular diaphragm)*2
Minimum Aperture	F22-40
Standard Accessories	Flower-shaped lens hood
Mount	CANON EF Mount (End of sale) NIKON F Mount (End of sale) SONY A Mount (End of sale)*3
Release Date	April 24, 2014 (CANON EF Mount) April 24, 2014 (NIKON F Mount) August 2, 2014 (SONY A Mount)

Specifications, appearance, functionality, etc. may be changed without prior notice.

*Length and weight are based on figures for the Nikon-mount lens.
*1 Length is the distance between the front tip of the lens and the mount face.
*2 This circular diaphragm stays almost perfectly circular up to two stops down from maximum aperture.
*3 The Sony mount does not include VC since Sony digital SLR bodies include built-in image stabilization functionality.
